ürün detay
OW14 OUTDOOR
OW14
Electrostatic powder paint coated extruded aluminum housing
IP67 Protection
IK08 Impact Protection
Electrical Safety Class I
bilgi_govde -- govde --
govde -
S304
S/N ( govdeS304 ),
S/N
PMMA Lens
UGR (CIE Pub.117):9
IEC/EN 62471 Photo-Biologic Protection RG0
bilgi_optik -- optik,ref --
optik -
0015,0030,0045,0060,OV24
15° ( optik0015 ),
15°
30° ( optik0030 ),
30°
45° ( optik0045 ),
45°
60° ( optik0060 ),
60°
15°-35° ( optikOV24 ),
15°-35°
SMD LED with a minimum lifetime of 100.000 hours
High color rendering index (CRI>70)
bilgi_led -- cri,cct --
cri -
7,8
CRI 70 ( cri7 ),
CRI 70
CRI 80 ( cri8 ),
CRI 80
cct -
27,30,40,50,57,65,00
2700K ( cct27 ),
2700K
3000K ( cct30 ),
3000K
4000K ( cct40 ),
4000K
5000K ( cct50 ),
5000K
5700K ( cct57 ),
5700K
6500K ( cct65 ),
6500K
Color LED ( cct00 ),
Color LED
Rated Input Voltage
220-240VAC
Input Voltage Range
176-264VAC
Frequency
50-60Hz
Power Factor
PF>0.95
Ambient Temperature
-20°C ~ +50°C
Constant Current Driver
Overload Protection (OLP), Overvoltage Protection (OVP), Short Circuit Protection (SCP), Over Temperature Protection (OTP)
bilgi_kontrol -- kontrol,kit --
kontrol -
O
ON/OFF 220VAC ( kontrolO ),
ON/OFF 220VAC
Luminaire Standard
EN 60598-1,EN 60598-2-13
Driver Standard
LVD (EN 61347-1, EN 61347-2-13),EMC ( EN 55015, EN 61547, EN 61000-3-2/3-3)
bilgi_standart -- --
"012":"12W",
"7":"CRI 70","8":"CRI 80",
"27":"2700K","30":"3000K","40":"4000K","50":"5000K","57":"5700K","65":"6500K","00":"Color LED",
"S":"Standard",
"S304":"S/N",
"0015":"15°","0030":"30°","0045":"45°","0060":"60°","OV24":"15°-35°",
"O":"ON/OFF 220VAC",
"S":"Standard",
"S":"No Kit",
"S":"Standard",
"67":"IP67",
Product Dimensions
Dimensions (mm) Mountage Size (mm) Weight (kg) 0
Packing Details
Quantity Per Carton (pcs.) 0 (width)*(lenght)*(height) (cm) 0 x 0 x 0 Gross Weight (kg) 0 Pack Deci (x*y*z) / 3000 0
OW14-0328 Wallwasher LED Lighting
** The values in above table are for standard products and light colors. The values may vary when the LED replaced with a LED having different performance or light color .
"024":"24W",
"7":"CRI 70","8":"CRI 80",
"27":"2700K","30":"3000K","40":"4000K","50":"5000K","57":"5700K","65":"6500K","00":"Color LED",
"S":"Standard",
"S304":"S/N",
"0015":"15°","0030":"30°","0045":"45°","0060":"60°","OV24":"15°-35°",
"O":"ON/OFF 220VAC",
"S":"Standard",
"S":"No Kit",
"S":"Standard",
"67":"IP67",
Product Dimensions
Dimensions (mm) Mountage Size (mm) Weight (kg) 0
Packing Details
Quantity Per Carton (pcs.) 0 (width)*(lenght)*(height) (cm) 0 x 0 x 0 Gross Weight (kg) 0 Pack Deci (x*y*z) / 3000 0
OW14-0653 Wallwasher LED Lighting
** The values in above table are for standard products and light colors. The values may vary when the LED replaced with a LED having different performance or light color .
"036":"36W",
"7":"CRI 70","8":"CRI 80",
"27":"2700K","30":"3000K","40":"4000K","50":"5000K","57":"5700K","65":"6500K","00":"Color LED",
"S":"Standard",
"S304":"S/N",
"0015":"15°","0030":"30°","0045":"45°","0060":"60°","OV24":"15°-35°",
"O":"ON/OFF 220VAC",
"S":"Standard",
"S":"No Kit",
"S":"Standard",
"67":"IP67",
Product Dimensions
Dimensions (mm) Mountage Size (mm) Weight (kg) 0
Packing Details
Quantity Per Carton (pcs.) 0 (width)*(lenght)*(height) (cm) 0 x 0 x 0 Gross Weight (kg) 0 Pack Deci (x*y*z) / 3000 0
OW14-0980 Wallwasher LED Lighting
** The values in above table are for standard products and light colors. The values may vary when the LED replaced with a LED having different performance or light color .
"048":"48W",
"7":"CRI 70","8":"CRI 80",
"27":"2700K","30":"3000K","40":"4000K","50":"5000K","57":"5700K","65":"6500K","00":"Color LED",
"S":"Standard",
"S304":"S/N",
"0015":"15°","0030":"30°","0045":"45°","0060":"60°","OV24":"15°-35°",
"O":"ON/OFF 220VAC",
"S":"Standard",
"S":"No Kit",
"S":"Standard",
"67":"IP67",
Product Dimensions
Dimensions (mm) Mountage Size (mm) Weight (kg) 0
Packing Details
Quantity Per Carton (pcs.) 0 (width)*(lenght)*(height) (cm) 0 x 0 x 0 Gross Weight (kg) 0 Pack Deci (x*y*z) / 3000 0
OW14-1313 Wallwasher LED Lighting
** The values in above table are for standard products and light colors. The values may vary when the LED replaced with a LED having different performance or light color .
